Biodegradable Paper Drinking Straw Making Machine

Availability:
Quantity:
  • PPZG

  • POLYPRINT

Feature:
Paper Straw Making Machine is suitable for different diameter (5-12 mm) paper tube production, such as paper straw, pen tube.

1. Machine adopts Siemens PLC control, all data can be display in the touch screen.

2. Numerical control servo cutter device, high precision cutting.
3. Automatically cut, automatically fall pipe, automatically change speed and revert.
4. Round knife cutting, incision more smooth, performance more stable.
5. With online multi-cut blades, no need secondary cutting, save labor and time.
6. Stainless steel gluing box, with polyurethane scraper and high carbon steel plastic knife, durable in use.
7. Machine adopts Flange for fix the mandrel.
8. Machine supply of lubricant automatically.

Technical Parameter:

1 Number of Roller 1-3 layer
2 Working Speed 150-250pcs/min, about 200pcs
3 Straw Diameter  5-10mm
4 Straw Wall-thickness 0.3-1.0 mm
5 Power Supply 380V/3Phase/50Hz
6 Machine Size 5600*1600*1750mm
7 Working Space 11000mm * 6000mm*2000mm
8 Weight 2000kgs


Samples:

O1CN01mUZaX61Gy3ms300CG_!!4086120690
