PP-390
POLYPRINT
8477590000
Feature:
It is suitable to form HIPS, PS, PVC and PET plastic sheets etc., which can produce various of seeds tray, flower pot etc.
Design Features:
Microprocessor-based control system (PLC)
High speed forming air
Multi zone heating controller through solid state relay
High quality lapped spool valves for all control functions
Automatic unwind and rewind equipment for material and web
Heating plate is moving, mould is un-moving.
Low air consumption
Low maintenance
Technical Parameter:
| 1. Forming Area | 390X600mm |
| 2. Forming Depth | 100mm |
| 3. Sheet Width | 390mm |
| 4. Sheet Thickness Range | 0.15-1.0mm |
| 5. Max.Sheet Roller Diameter | 710mm |
| 7. Water Consumption | 10Liters/min(15-25 C) |
| 8. Air Consumption | 1200 Liters/min |
| 9. Speed | 15-25 Cycles/min |
| 10. Power | Three-phase four-wire AC380v+-15v |
